The Building

Cross-Section

Click Cross-Section to Enlarge

Outline Specification

  • HQ office building
  • Full Grade A specification
  • Highly efficient and flexible floor plates
  • Impressive double height reception
  • LEED Platinum targeted
  • Reception, lobby, toilet and shower facilities finished to the highest corporate standard
  • Bike & shower facilities
  • Excellent natural light to all floors
  • Standby generator
  • Perforated metal ceiling tiles
  • Efficient LED PIR lighting
  • Raised access floors
  • 4 pipe air conditioning system with thermal storage bank (occupancy density 1:7m²)
  • 6 high speed 17 passenger lifts (1 Goods Lift)
  • Rain water harvesting system
  • Raised access floor void 200mm (8”)
  • Suspended ceiling void 400mm (1’ 4”)
  • Floor to ceiling height of 2.83m (9’ 3”)

Floorplans

Click on a floor in the below table to view relevant floorplan or use the arrows to navigate

Schedule of
Accommodation

Ground Floor
FLOOR SQ.M SQ.FT
Ground 1,576 16,964

Ground Floor

1,576 SQ.M | 16,964 SQ.FT

First Floor
First 1,625 17,491

First Floor

1,625 SQ.M | 17,491 SQ.FT

Second Floor
Second 1,961 21,108

Second Floor

1,961 SQ.M | 21,108 SQ.FT

Third Floor
Third 1,961 21,108

Third Floor

1,961 SQ.M | 21,108 SQ.FT

Fourth Floor
Fourth 1,889 20,333

Fourth Floor

1,889 SQ.M | 20,333 SQ.FT

Fifth Floor
Fifth 1,889 20,333

Fifth Floor

1,889 SQ.M | 20,333 SQ.FT

Sixth Floor
Sixth 1,820 19,590

Sixth Floor

1,820 SQ.M | 19,590 SQ.FT

Seventh Floor
Seventh 1,743 18,761

Seventh Floor

1,743 SQ.M | 18,761 SQ.FT

Eighth Floor
Eighth 1,414 15,220

Eighth Floor

1,414 SQ.M | 15,220 SQ.FT

Basement
Basement

Basement Floor

Roof Level
Roof Level
Total 15,878 170,908

Roof Level

The above areas are based on single occupancy.

45 Basement Level Car Parking Spaces

Download Floor Plans

Areas

FLOOR SQ.M SQ.FT
Ground 1,576 16,964
First 1,625 17,491
Second 1,961 21,108
Third 1,961 21,108
Fourth 1,889 20,333
Fifth 1,889 20,333
Sixth 1,820 19,590
Seventh 1,743 18,761
Eighth 1,414 15,220
TOTAL 15,878 170,908

The above areas are based on single occupancy.

Space Plans

Floor plates allow For maximum flexibility and
ease of configuration for all occupier types

PROFESSIONAL SERVICES LAYOUT

Click Space plan to Enlarge

Open Plan Workstations 137
Work Stations within cellular offices 22

Total 159

DENSITY 1:12 SQ.M

Meeting Rooms/ Video Conference

4 person room x 2
6 person room x 1
10 person room x 1
12 person room x 1
14 person room x 1
20 person room x 1

Ancillary space includes

Reception area with seating
Large comms room
Large kitchen area
Large breakout space
Filing facilities throughout the floor plan

Not to scale: for indicative purposes only.

FINANCE LAYOUT

Click Space plan to Enlarge

Open Plan Workstations 234
Work Stations within cellular offices 6

Total 240

DENSITY 1:8 SQ.M

Meeting Rooms/ Video Conference

4 person room x 1
6 person room x 2
12 person room x 2
Telephone booths x 3

Ancillary space includes

Reception area with seating
Large comms room
Kitchen breakout areas
Large filing facilities

ICT LAYOUT

Click Space plan to Enlarge

Open Plan Workstations 182
Work Stations within cellular offices 6

Total 188

DENSITY 1:10 SQ.M

Meeting Rooms/ Video Conference

4 person room x 3
6 person room x 1
10 person room x 1
14 person room x 1
Telephone booths x 3

Ancillary space includes

Reception area with seating
Large comms room
Large kitchen area
Large breakout areas

*Meeting rooms could be designed to have flexible wall construction to allow for formation of large “town hall” type meeting space

Floor Plate Flexibility

Sample

Two Tenants per Floor Option 1

Two Tenants per Floor Option 1

Click Floor Plate to Enlarge

tenant one (Third Floor Area: 1001 sq.m)

tenant two (Third Floor Area: 910 sq.m)

Two Tenants per Floor Option 2

Two Tenants per Floor Option 2

Click Floor Plate to Enlarge

tenant one (Third Floor Area: 885 sq.m)

tenant two (Third Floor Area: 1025 sq.m)

POSSIBLE EXPANSION INTO EXISTING PARK PLACE DEVELOPMENT

Potential Expansion Into Block B

Potential Expansion Into Block B

Click Floor Plate to Enlarge

Potential Expansion Into Block C & A

Potential Expansion Into Block C & A

Click Floor Plate to Enlarge

View 07 View04_2K0A1750
view 08_2k0a1914_offset_EDITED
Reception
Lift Lobby
View Bathroom
Shower Room
Shower Room
Office Fit-out
Office Fit-out
Office
Office
